| UHF RFID |
| Frequency band | ETSI 865 – 868 MHz, FCC 902 – 928 MHz |
| Gain | 6 dBic |
| Beam Width (-3dB) | 60° |
| Polarization | RHCP |
| Input Impedance | 50 Ω |
| VSWR | < 1.5:1 |
| Maximum input power | 10W |
| Front-to-back Ratio | 23 dB |
| Connector | SMA Female connector (with 32 cm coaxial cable) |
| SIZE AND WEIGHT |
| Dimensions | (W) 300 x (L) 300 x (H) 6 mm / (W) 11.8 x (L) 11.8 x (H) 0.2 inch |
| Weight | 810 g / 28.6 oz |
| ENVIRONMENT |
| Operating Temperature | -20°C to 55°C -4°F to 130°F |
| Storage Temperature | -40°C to 85°C -40°F to 185°F |
ANTENNA RADIATION PATTERN
