UHF RFID
Supported standard
Frequency band
Regulatory
ISO 18000-63 (EPC Class 1 Gen2v2) ETSI 865.6-867.6 MHz and FCC/IC 902-928 MHz
Max sensitivity
87dBm
Typical reading speed
Up to 1000 tags/second
Radiated power
(integrated antenna)
Maximum: 33 dBm (2W) ERP / 3.3 W EIRP
Minimum: 4 dBm (2.5mW) / 4 mW EIRP
Integrated antenna features
Wide band antenna which covers ETSI and FCC/
IC frequency band, 7dBIc circular polarized, Beam width 80°
Conducted power for external antenna ports
+30dBm
External antenna port
3 ports RP-SMA female
RFID module
Nordic ID NUR3-1W, powered by Impinj E710
RAIN RFID chip



PLATFORM
CPUQuad-core A7 1.1GHz
Operating system
Customized Linux
Memory
1GB RAM 8GB Flash


USER INTERFACE
Indicators
4 pcs LEDs: Connection, Error/status, Power, RF Buzzer for sound indications


CONNECTIVITY
GPIO
Industrial mini IO port (4 GPIO)
USB
USB host, type A USB device,
type C (CDC serial port and HID profiles supported)
LAN
Ethernet 10/100 Mbit
Wireless LAN2.4G/5G, 802.11 a/b/g/n
Bluetooth
BT 2.1 + EDR/3.0/4.1 LE /BT4.2
Bluetooth profiles
SPP, HID, HOGP (HID over GATT)


POWER
External power
PoE+ 802.3at
Operating power
12W with maximum RFID transmission level and all the radios (WLAN and Bluetooth) enabled. 4W in idle state, with RFID and all the radios


SIZE AND WEIGHT
Dimensions
(W) 200 x (L) 260 x (H) 36 mm /
(W) 7.9 x (10.2 x (H) 1.4 inch
Weight
773gr


ENVIRONMENT
Environmental sealing
IP20, for indoor use only
Inbox content
1 WLAN/Bluetooth antenna
Operating temperature
-20 °C to 55 °C (-4 to 130 °F)
Storage temperature
-40 °C to 85 °C (-40 to 185 °F
Mounting
VESA 75/100 Compatible


SOFTWARE INTERFACE
Data management
Nordic ID Radea
Firmware update
Via Web management UI and the RESTful service
Management interface
Web management UI and SSH for developers
IP Address configuration
IPv4 DHCP or Static IP
API support
NUR API for RFID and RESTful service to access reader configuration
Software development
Ready-to-use Nordic ID NUR API that provides full control over the reader.
Application can be written with modern programming languages. MQTT support (broker or client). Compatible with existing Nordic ID fixed readers
Security
TLS v1.3, WLAN profiles: WPA2-Personel and WPA2- Enterprise (PEAP-MSCHAPV2 and EAP-TTLS/PAP)
