UHF RFID IDENTIFICATION
Supported standardISO 18000-63 (EPC Class 1 Gen2v2)
Frequency ETSI 865.6–867.6 MHz or FCC/IC 902–928 MHz
RF radiated powerMax. ERP 2 W (33dBm) / EIRP 3.3 W (35.2dBm) Adjustable in 1dB steps (30 steps)
Antenna features
  • Software controllable antenna polarizations (vertical, horizontal or vertical/horizontal switching)
  • Reading range up to 15 m / 50 f
Max receive sensitivity-80 dBm
Typical reading speedUp to 1000 tags per second



BARCODE IDENTIFICATION AND IMAGING
2D imager
  • All major 1D barcodes and 2D codes
  • High visibility LED aimer
  • 2 characters pre and post fixes, padding, replacement
  • Enhanced aiming mode (automatic switching between scan line / aiming dot)
  • Configurable scan alert sounds
Camera5 Mpix rear-facing camera with auto focus and LED flash (torch mode supported)


PLATFORM
RFIDNordic ID NUR2-1W reader module
CPUOcta-Core ARM Cortex-A53 1.8 GHz
Operating systemAndroid 10
Memory
  • 2 GB RAM
  • 16 GB Flash
  • MicroSD slot with support for SDXC cards
SensorsAccelerometer, ambient light sensor, Time of Flight sensor (only in barcode variant), proximity sensor, pedometer, gyroscope


USER INTERFACE
Display
  • 4.7 HD capacitive touch screen, 1280 x 720 pixels, 16.7 M colors
  • Adjustable LED backlight, Daylight readable, Gorilla glass 3, usage with gloves supported
Keypad3 backlit physical keys below the display,
2 customizable trigger buttons on the sides
1 trigger button on the pistol grip
AudioMicrophone, earpiece and IHF speaker
Signals and indicatorsRGB LED and vibra for haptic feedback


DROP AND SHOCK
Drop and impact resistance1.6 m / 5.2ft
ESDContacts +/-4 kVdc
Air discharge +/-8 kVdc


CONNECTIVITY
Wireless WAN (optional)Europe
  • 4G LTE (B1/B3/B5/B7/B8/B20/B28A/B38/B40/B41)
  • 3G WCDMA (B1/B2/B5/B8)
  • GPRS / EDGE (850/900/1800/1900
GNSS (optional)Assisted GPS, BeiDou, GLONASS and Galileo
Wireless LANIEEE 802.11 a/b/g/n/ac. Dual band WLAN, supports 2.4 GHz and 5 GHz networks
Wireless PAN
  • Bluetooth 4.2 Class 2
  • Classic and Low Energy modes supported
PAN
  • USB 2.0 via USB Type-C connector
  • Desktop charger provides USB connectivity via USB Type-C connector
NFCNFC standards supported: ISO/IEC 14443A, ISO/IEC 14443B, FeliCa, ISO/IEC 15693 (Vicinity)


POWER
Battery
  • Rechargeable, removable Lithium Ion battery: 10050 mAh, 3.6 V
  • Up to 18 hours in intensive use
Charging
  • Charging over desktop charger (0 to 80 %) 4 hours
  • Charging over USB Type-C connector (0 to 80 %) 4 h (with charger supporting Qualcomm Quick Charge 3.0)
External power supply
  • AC adapter for desktop charger: input 100-240 VAC, 1A, 50-60 Hz / output 24 VDC, 1.25A, 30 W / Power cable for EU, UK or US
  • AC adapter for multiunit desktop charger: input 100- 240 VAC, 1A, 50-60 Hz / output 24 VDC, 6.25A / 150W / Power cable for EU, UK or US
Backup batteryFor real-time clock: keeps time for 200 days
Battery Hot Swap
Supported


SIZE AND WEIGHT
Dimensions
(H) 214 x (W) 87/72 x (D) 135/29 mm
(H) 8.4 x (W) 3.4/2.8 x (D) 5.3/1.1 inch
Weight
642 gr / 22.65 oz


ENVIRONMENT
Temperature
Operating                -20° to +55 °C              -4 to +131 °F

Storage                    -20° to +60 °C              -4 to +140 °F

Charging                     0° to +45 °C           +32 to +113 °F

Relative humidity10 % to 95 % non-condensing
Environmental sealingIP65
