CONFIGURING HID MODE WITH BARCODE
Read barcode below to configure the Nordic ID EXA31 to desired HID mode. Please note barcode configuration codes can be read only when there is no active Bluetooth connection with the host device.
• HIDMODE0 = All HID modes disabled
• HIDMODE1 = HID barcode enabled
• HIDMODE2 = HID RFID enabled
Both HIDMODE1 and HIDMODE2 can be simultaneously enabled.
CONFIGURING HID MODE WITH APPLICATION
1. Install Nordic ID RFID Demo application
Google Play store
https://play.google.com/store/apps/details?id=com.nordicid.rfiddemo&hl=en_US
Apple App store
https://apps.apple.com/us/app/nordic-id-rfid/id1161741591
2. Connect your reader to application
3. Confirm that pairing is enabled in reader settings
4. Turn on HID mode, RFID and/or barcode mode in reader settings
5. Close application and make sure Bluetooth connection is closed
6. Reboot your EXA31 device by pressing the power button for 2...3 seconds
